V-Funnel Test for Self-Compacting Concrete

Fill the V-shaped funnel, open the trapdoor and time the emptying — a flow time of 10 seconds is considered appropriate for self-compacting concrete.

Constropedia Editorial First published October 2021 · Updated September 2026 · 2 min read

Self Compacting Concrete

It is a special type of concrete. It has excellent deformability, so it can be moulded without any vibration. Its cohesive nature makes it resistant to bleeding and segregation at the time of handling.

Mix design to your standard Concrete Calculator All in One has a mix design library to Indian, British, Canadian, Australian, Asian and US/ACI standards.
Try the app

V funnel Test

This test was developed in Japan. The equipment consists of a V-shaped funnel. The V-funnel test is used to measure the filling ability of self-compacting concrete and can also be used to judge segregation resistance. V Funnel apparatus is used to evaluate the flow time of freshly mixed self-compacting concrete. The test is not suitable when the maximum size of the aggregate exceeds 22.4 mm. The test set consists of a stainless steel funnel placed vertically on a supporting stand. The discharge orifice is equipped with a lid, which can be momentarily opened. Basically this test is useful for Flow capacity of self compacting concrete.

Apparatus

V funnel: It is main apparatus.

Blue steel V-funnel apparatus mounted vertically on a four-legged stand

Bucket: To store discharged concrete

Trowel: For leveling

Clip-art hand trowel with a wooden handle

Scoop: For filling Concrete

Stopwatch: To record Time

Clip-art stopwatch

Procedure

  • Take 12 litres of self compacting concrete.
  • Set V funnel on leveled and firm ground.
  • Fill the funnel with concrete. Open the funnel within 10 seconds of filling.
  • Start the stopwatch when the funnel is opened and record the time of emptying.
  • This all should be done in 5 min.

Procedure for Flow Time at T5 Minutes

  • Do not clean the funnel from inside. Close the trapdoor and pour concrete again in the funnel. Do not compact or vibrate it.
  • Wait for 5 minutes, then open the trapdoor.
  • Record time of emptying funnel from opening the trapdoor.
  • This is the time when light is seen from the top of the V funnel (T5).

Result

For SCC a flow time of 10 seconds is considered appropriate.
